I think we all can agree that TAB completion is very useful and time saving feature that a lot of native PowerShell functions offer. But did you know that you can make this useful feature available even for your own custom functions?

In this post, I will show you two ways to make this work 👍

PS: By TAB completion I mean pressing TAB key to get available parameter values

---

1. TAB completion defined globally for list of functions

The key here is to use Register-ArgumentCompleter PowerShell function.

Be noted that effect of using Register-ArgumentCompleter won't outlast console closure. To make it "permanent" place the code into your PowerShell profile script.

Register-ArgumentCompleter has three important parameters:

• 1.CommandName
  • List of functions/cmdlets this TAB completion will be applied to
• 2.ParameterName
  • CommandName parameter name this TAB completion will be applied to
• 3.ScriptBlock
  • Special crafted scriptBlock, whose output will be shown as TAB completion

Basic example

# some dumb function with at least one parameter (fullName in this example)
function Open-DesktopFile {
    param ($fullName)

    # open given file
    & $fullName
}

# scriptblock for Register-ArgumentCompleter
$openDesktopSb = {
    param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParams)

    $DesktopPath = [Environment]::GetFolderPath("Desktop")

    Get-ChildItem -Path $DesktopPath -File | Where-Object { $_.Name -like "*$WordToComplete*" } | Select-Object -ExpandProperty FullName | ForEach-Object { "'$_'" }
}

# activate `TAB` completion for 'Open-DesktopFile' functions parameter 'fullName'
# what pressing of `TAB` returns, is defined in openDesktopSb scriptblock
Register-ArgumentCompleter -CommandName Open-DesktopFile -ParameterName fullName -ScriptBlock $openDesktopSb

# now call Open-DesktopFile -fullName (and hit `TAB` key to fill it)

Silly example above shows basic scriptBlock for filling path to quoted files on your desktop.

As you can see, the Register-ArgumentCompleter scriptBlock operates with five automatically filled parameters: $commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParams (their names doesn't matter, just their position!)

• commandName
  • contains name of the function to which this completion will be applied to
• parameterName
  • contains name of the parameter to which TAB will be applied to
• wordToComplete
  • contains string user have entered (if any)
• commandAst
  • contains AST object of the current input line
• fakeBoundParams
  • contains hashtable containing the $PSBoundParameters for the commandName function, before the user pressed TAB

PS: scriptBlock will be run with each hit of TAB key! So make it as resource efficient as you can.

Example of leveraging fakeBoundParams parameter

• We all use Get-WmiObject and Get-CimInstance cmdlets, but wouldn't be nice to have TAB completion for Class name? Moreover for different Namespaces? 😉

$wmiClassSb = {
    param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParams)

    if ($fakeBoundParams.Namespace) {
        # use user entered namespace if available
        $Namespace = $FakeBoundParams.Namespace
    } else {
        # use default namespace
        $Namespace = "ROOT\cimv2"
    }

    Get-WmiObject -List -namespace $Namespace | ? {$_.Name -like "*$WordToComplete*"} | select -exp name
}

# make `TAB` completion work for Class parameter of Get-WmiObject, Get-CimInstance commands
Register-ArgumentCompleter -CommandName Get-WmiObject, Get-CimInstance -ParameterName Class -ScriptBlock $wmiClassSb

The result will look like this

---

2. TAB completion defined in function param() section

• As you already know, parameters defined in PowerShell param() block, can have various attributes like type, validation etc. One of this attributes is ArgumentCompleter and is used to define TAB completion
  • The usage is like this:

function Invoke-Greeting {
    param (
        [ArgumentCompleter( {
                param ($Command, $Parameter, $WordToComplete, $CommandAst, $FakeBoundParams)

                Get-LocalUser | Where-Object { $_.Name -like "*$WordToComplete*" }
            })]
        [string] $userName
    )

    "Say hi to $userName"
}

# to test this out, call Invoke-Greeting and just hit TAB to show local user names

• So for specific parameter ($userName in this case) you define [ArgumentCompleter({ <scriptBlock> })]
  • The <scriptBlock> has same format as for Register-ArgumentCompleter function, so check first section of this post for more details

And the result will look like this

---

Various examples just for inspiration

Search AD computer by its name or description

• very handy if you have a lot of servers, and you save their purpose to their description attribute!

  $computerSB = {
       param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParameter)

       $searcher = New-Object System.DirectoryServices.DirectorySearcher (([adsi]"LDAP://OU=Computer_Accounts,DC=contoso,DC=com"), '(objectCategory=computer)', ('name', 'description'))
       ($searcher.findall() | ? { $_.properties.name -match $wordToComplete -or $_.properties.description -match $wordToComplete }).properties.name | Sort-Object | % { "'$_'" }
       $searcher.Dispose()
   }

   # TAB completion of AD computer names in computerName parameter of any command from module Scripts, ..
   Register-ArgumentCompleter -CommandName ((Get-Command -Module Scripts).name) -ParameterName computerName -ScriptBlock $computerSB
   Register-ArgumentCompleter -CommandName Enter-PSSession, Invoke-Command -ParameterName computername -ScriptBlock $computerSB
   # TAB completion of AD computer names in identity parameter of commands with "computer" in their name from module ActiveDirectory
   Register-ArgumentCompleter -CommandName ((Get-Command -Module ActiveDirectory -Noun *computer*).name) -ParameterName identity -ScriptBlock $computerSB


  Similarly if you have functions related to server or clients, you can limit the completion like this

   $serverSB = {
       param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParameter)

       $searcher = New-Object System.DirectoryServices.DirectorySearcher (([adsi]"LDAP://OU=Servers,OU=Computer_Accounts,DC=contoso,DC=com"), '(objectCategory=computer)', ('name', 'description'))
       ($searcher.findall() | ? { $_.properties.name -match $wordToComplete -or $_.properties.description -match $wordToComplete }).properties.name | Sort-Object | % { "'$_'" }
       $searcher.Dispose()
   }

   Register-ArgumentCompleter -CommandName Invoke-MSTSC -ParameterName computerName -ScriptBlock $serverSB

   $clientSB = {
       param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParameter)

       $searcher = New-Object System.DirectoryServices.DirectorySearcher (([adsi]"LDAP://OU=Clients,OU=Computer_Accounts,DC=contoso,DC=com"), '(objectCategory=computer)', ('name', 'description'))
       ($searcher.findall() | ? { $_.properties.name -match $wordToComplete -or $_.properties.description -match $wordToComplete }).properties.name | Sort-Object | % { "'$_'" }
       $searcher.Dispose()
   }

   Register-ArgumentCompleter -CommandName Assign-Computer -ParameterName computerName -ScriptBlock $clientSB


Or what about replacing name for samaccountname in identity parameter of all functions from ActiveDirectory module (that contains 'User' in noun part)?

    $userSB = {
        param ($commandName, $parameterName, $wordToComplete, $commandAst, $fakeBoundParameter)

        $searcher = New-Object System.DirectoryServices.DirectorySearcher (([adsi]"LDAP://OU=User_Accounts,DC=contoso,DC=com"), '(objectCategory=user)', ('name', 'samaccountname'))
        ($searcher.findall() | ? { $_.properties.name -match $wordToComplete }).properties.samaccountname | Sort-Object | % { "'$_'" }
        $searcher.Dispose()
    }

    Register-ArgumentCompleter -CommandName ((Get-Command -Module ActiveDirectory -Noun *user*).name) -ParameterName identity -ScriptBlock $userSB

---

Summary

As you can see, you have two options to define TAB completion. Inside the function param() block using [ArgumentCompleter()] or globally using Register-ArgumentCompleter. In general I use the latter option in my PowerShell profile script mainly for built-in functions and the first one, for my own custom functions. In either way, its very handy, time saving and cool feature! 😉

Do you have any other cool examples of TAB completion?
